Product Description

Power Required 50-75 hp Drive Type Gearbox with belt
Minimum Power 50 hp Number of Belts 5
Working Width 72 in Belt Type AV 17*1245
Overall Width 81 in Drive Blet Tensioner Yes, bolts tightened
Variable Cutting Height 0-3 in Deck Material 0.2 in
Horicontal Etending Distance 13 in Side Plate Material 0.3 in
With Rear Open Door 1 pcs rear open door PTO Shaft RPM 540 rpm
Blade Number 16 Driveline Shaft Length 39-50 in
Blade Type hammer Spline End:   PTO Shaft Spline 1.375"  z6
Blade Weight 2.7 lbs 3-Point Hitch CAT 2
Blade Material Cast steel Tractor Mount Three-point hitch
Rotor Bearing SKF Bearing Gearbox 0il Type 85W/90
Rotor Diameter 6 in Dimensions (L x W x H) 81x46x37 in
Rotor Swing Diameter 16 in  Packing Size  82x38x28 in
Rotor Thickness 0.3 in Finsh  Durable Powder Coated finish
Rotor Shaft Speed 2082 rpm Warranty 1 year
Blade Speed

31.5 mph

Net Weight 1085 lbs
Rotor Rotation Clockwise Gross Weight 1232 lbs

WARNING: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soot, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.

Questions? Call or text (888) 608-7866 or email johnm@summitsourceusa.com.
